SHACMAN L3000 4×2 10-cubic-meter Sweeping Vehicle - Efficient Operation, Setting a New Benchmark for City Cleanliness Protection

Three core advantages in brief description:
1. Powerful powertrain, suitable for all scenarios of operation: Equipped with efficient engines from Wuxi Changan/Yuchai series, paired with Fastrat 8-speed transmission, 4×2 drive form combines the flexibility of urban roads with the load-bearing capacity for complex conditions. With a full tank of 10 cubic meters, it still has abundant power for climbing slopes and starting/stopping, easily handling various scenarios such as municipal sanitation, landscaping, and dust suppression at construction sites.
2. 10-cubic-meter large-capacity tank, high-quality craftsmanship with zero leakage: Using 4mm thick high-quality carbon steel (optional stainless steel) tank body, formed by automated welding process, the tank body is reinforced with double support from the main beam, ensuring perfect sealing performance; standard equipment includes front flushing, side spraying, high cannons and other multi-functional operation devices, with full efficiency of self-suction and self-discharge, and the suction depth can reach over 6 meters.
3. Humanized and comfortable cabin, intelligent and safe dual upgrades: The L3000 driver's cabin is equipped with air conditioning, electrically adjustable windows, central locking, hydraulic shock-absorbing seats, making long-distance operation more comfortable; the entire vehicle is reinforced with braking and suspension systems, paired with LED daytime running lights, providing comprehensive safety protection, and also supports customized configurations for export, adapting to different regional regulations worldwide.

product details

specification

Detailed Introduction of SHACMAN L3000 4×2 10-Cylinder Water Spraying Vehicle

1. Core of the chassis: SHACMAN technology endorsement, reliability at its peak

The SHACMAN L3000 4×2 10-cubic-meter water tanker is built on the Shaanxi Auto DeLong L3000 medium-duty truck chassis. It adheres to the military-grade manufacturing standards of Shaanxi Heavy Trucks and is a star product in the fields of municipal sanitation, construction engineering, and landscaping.

• Power System: Optional Wuxi WP6 series (210-245 horsepower) or Cummins engine. The power output is strong and the fuel economy is excellent, meeting the emission regulations of different regions. It is matched with classic 8-speed transmissions such as Fatao 8JS85T, with smooth shifting and high transmission efficiency, suitable for the frequent start-stop operation characteristics of water tanker trucks.

• Chassis structure: 4×2 drive mode, 4500mm golden axle distance. The vehicle body is compact and flexible, perfectly suitable for urban narrow roads, residential streets and other working scenarios. The frame is made of high-strength steel, and is equipped with 10.00R20 steel wire tires. It has strong load-bearing capacity and excellent stability in bumpy road conditions. The braking system has been comprehensively upgraded, and is combined with the ABS anti-lock system, ensuring greater safety during operation.

• Cab configuration: L3000 wide-body cab, with ample and transparent interior space. Standard features include air conditioning, electric sliding windows, central locking (with dual remote controls), hydraulic main seat (optional air-damped seat), third seat, manual/automatic folding cab design, easy maintenance and servicing; the cab has excellent sound insulation and vibration reduction effects, significantly reducing the fatigue of the driver during long-term operations.

Upper Garment System

10 large-capacity compartments, versatile and all-inclusive for various operations

The upper part of the vehicle is designed with industry-leading technology for sanitation vehicles. It features a standard 10 cubic meter (10,000 liters) tank capacity. According to customer requirements, a 12-15 cubic meter (12,000-15,000 liters) expanded version can be customized to meet different operational needs.

• Tank body manufacturing: The tank body is made of high-quality carbon steel Q235 (food-grade stainless steel is also available as an option). The tank body is composed of 4mm thick plates + 4mm head. It is formed through advanced processes such as automatic plate assembly welding and ring-shaped automatic welding. The interior of the tank is treated for anti-corrosion and rust prevention, ensuring a service life of over 10 years. The tank body is connected to the main beam using double supports and fixed with bolts. It will not shift or leak even under bumpy road conditions. The tank top is equipped with a non-slip operation platform and safety guardrails to ensure the safety of operators.

• Operating System: Standardly equipped with a high-power stainless steel sprinkler pump, with a flow rate of 60-90 m³/h, self-priming height ≥ 6 meters, and high self-priming and self-discharge efficiency, enabling quick filling of the tank; standard features include front flushing (road cleaning, width ≥ 14 meters), rear spraying (road dust reduction, width ≥ 10 meters), side spraying (garden greening irrigation), and rear working platform high-pressure cannon (range ≥ 28 meters, adjustable from columnar to mist form), while also providing a fire-fighting interface for emergency water supply and firefighting operations; all pipelines and valves are made of high-quality stainless steel, resistant to corrosion, easy to maintain, and designed with bolt connections, facilitating disassembly and maintenance.

• Customization Options: Supports the installation of fog cannons (30-100 meter range), electric sprinkler guns, tank heating and insulation devices, GPS positioning systems, video monitoring, etc., suitable for multiple scenarios such as dust suppression vehicles, water transport vehicles, and fire water supply vehicles, and also supports export customization of left/right steering and different country regulations certifications.

Application Scenarios and Product Value

The SHACMAN L3000 4×2 10-cubic-meter water tanker is a versatile cleaning vehicle widely used in:

• Municipal sanitation: urban road cleaning, dust reduction, cooling, disinfection of garbage stations, post-rain road dredging;

• Greening: watering of trees and plants, spraying pesticides in green belts, park water replenishment;

• Construction: dust control at construction sites, washing of construction vehicles, road watering for dust reduction;

• Emergency support: water transportation for drought relief, emergency fire water supply, post-emergency pollution flushing.

As the main product of SHACMAN's export-oriented sanitation vehicles, the L3000 water tanker, with its core advantages of "reliable chassis, durable upper structure, and flexible configuration", has been exported to multiple countries and regions around the world, including the Middle East, Africa, and Southeast Asia, and has become the preferred sanitation equipment for overseas customers due to its high cost-effectiveness and low maintenance costs. The entire vehicle has passed strict reliability tests and operates stably in extreme environments such as high temperatures, high altitudes, and dust, truly achieving the "one vehicle, all scenarios, long lifespan" operational value.

specification

Modle:	SHACMAN SX3318DT404	Engine:	Diesel
Transmission:	Manual	Axle:	MAN 29.5T /216T Double-stage,speed Ratio-5.92
Wheel Base:	1800+3775+1400mm	Tire:	12.00R20
Fuel Tank:	400L	Clutch:	p430 Diaphragm Spring Clutch
Air Inlet:	Ordinary Air Filter	Chassis:	850x300(8+7)
Suspension:	Front /rear Multi-layer Plate Spring 4 Main Plates + 4 U-shaped Bolts	Cabin:	Medium-length Flat Top
